Slurry Mixing Skid (Dual Tanks)

The Dutch Filtration dual mixing slurry skid is a complete unit for pre-coating and body feed the filter press. The unit is complete with 2 mixing tanks both 2.3m3, air driven pre-coat and body feed pump. The frame is equipped with a working platform for safe and easy adding filter aid (DE media) into the mix tanks. The return to pre coat line are equipped with two connections for dosing the DE media from the safe powder handling system.

* Frame designed and certified according to DNV 2.7-1

* Air driven precoat and body feed pump

* 2x15 bbl mixtank

* All wetted parts SS316

* Connections unions fig. 206

* Air agitation system

Features

Benefits

* Globally accepted for offshore use

* Reliable system with backup pump

* 2 Seperate mix tanks for maximum flexibility

* No corrosion issues

* No moving parts, easy and reliable mixing

* Completion fluids

* Work over fluids

* Gravel pack fluids

* Wellbore clean up fluids

* (Bio) diesel

Applications

* Surface water intake

* Process water

* Frac fluids

* Waste water
